2023 John Deere 320G
2023 John Deere 320G skid steer loader. 628 hours. Listed from Oklahoma City, OK. Stock 23076. Asking $59,449.
- Asking
- $59,449
- Hours
- 628
- Stock #
- 23076
- Location
- Oklahoma City, OK
- Listed by
- CL Boyd
Sales desk 9 to 5 Central · Live Agent 24/7
Essentials
- Stock
- 23076
- Class
- Skid Steer Loaders
- Engine
- 3.3L Yanmar 69 HP FT4 Diesel Engine
- Yard
- Oklahoma City, OKSee what else is here.
- Sale
- No bidding · no premium
- Listed by
- CL Boyd
Specification
| Engine manufacturer and model | Yanmar 4TNV98C (optional 4TNV98CT) |
|---|---|
| Non-road emission standard | EPA Final Tier 4 (FT4)/EU Stage IV |
| Gross rated power (ISO 14396) | 51.7 kW at 2,500 rpm (69 hp at 2,500 rpm) |
| Net peak power (SAE J1349 / ISO 9249) | 49.4 kW at 2,500 rpm (66 hp at 2,500 rpm) |
| Displacement | 3.3 L (203 cu. in.) |
| Operating weight, base machine | 3246 kg (7,150 lb.) |
| Tipping load | 1989 kg (4,380 lb.) |
| SAE rated operating capacity | 994 kg (2,190 lb.) |
| SAE rated operating capacity with counterweight | 1067 kg (2,350 lb.) |
| Boom breakout force with foundry bucket | 1692 kg (3,725 lb.) |
| Bucket breakout force with foundry bucket | 2724 kg (6,000 lb.) |
| Pump flow, standard | 78 L/m (21 gpm) |
| Pump flow, total with high-flow option | 112 L/m (30 gpm) |
| Fuel tank | 79 L (21 gal.) |
| Travel speed, 2-speed high (standard) | 19.3 km/h (12 mph) |
| Height to hinge pin | 3.10 m (10 ft. 2 in. (122.2 in.)) |
Sales desk is 9 to 5 Central. Live Agent is on 24/7 — call, text, or chat.
Is the John Deere 320G a compact track loader?
No. Official OEM sheets DKAGSS320 (24-03) and DKAGSSL title the 320G as a skid steer loader (SSL). The mid-frame CTL counterpart is the 325G. Do not mix CTL track specs into this key.
What engine and horsepower does the 320G have?
FT4 column: Yanmar 4TNV98C, 3.3 L (203 cu. in.), 4 cylinders. Gross rated power 51.7 kW (69 hp) at 2,500 rpm; net peak power 49.4 kW (66 hp) at 2,500 rpm (SAE J1349 / ISO 9249).
What is the rated operating capacity?
SAE rated operating capacity is 994 kg (2,190 lb.); with counterweight 1067 kg (2,350 lb.). Tipping load 1989 kg (4,380 lb.).
What does the base machine weigh?
Base machine operating weight is 3246 kg (7,150 lb.) with standard equipment, full fuel, and 79-kg operator.
What hydraulic flows are listed?
Standard pump flow 78 L/m (21 gpm); total with high-flow option 112 L/m (30 gpm). System pressure at couplers 22 408 kPa (3,250 psi).
Is this the same as a 320 P?
No. 320 P-Tier is a different product family (backhoe). This pack is G-Series 320G SSL only.
How many hours are on this 2023 John Deere 320G?
611 hours.
What is the asking price and location?
$59,449 in Oklahoma City, OK. Stock 23076.
