2020 John Deere 672G

7,899 hrs · Oklahoma City · Stock 25643

2020 John Deere 672G motor grader. 7,899 hours. Listed from Oklahoma City, OK. Stock 25643. Asking $189,000.

Asking: $189,000
Hours: 7,899
Stock #: 25643

Location: Oklahoma City, OK
Listed by: CL Boyd

Sales: (405) 873-7772 Email: sales@trackandblade.com

Sales desk 9 to 5 Central · Live Agent 24/7

Essentials

Stock: 25643
Class: Motor Graders
Engine: John Deere 9.0L 255 HP Series Turbocharged & Charge-Air-Cooled FT 4 Diesel Engine
Yard: Oklahoma City, OKSee what else is here.
Sale: No bidding · no premium
Listed by: CL Boyd

Other 672Gs listed

2019 John Deere 672G6,991 hrs$194,000

2019 John Deere 672G8,061 hrs$189,000

2019 John Deere 672G7,045 hrs$189,000

2019 John Deere 672G6,159 hrs$189,000

This 672G vs others listed

Same 672G: hours and asking from listings live today.
Unit	Hours	Asking
2019	6,159	$189,000
2019	6,991	$194,000
2019	7,045	$189,000
This unit	7,899	$189,000
2019	8,061	$189,000

Specification

Engine manufacturer and model (FT4/Stage V column)	John Deere PowerTech PSS 9.0L
Displacement	9.0L (548 cu. in.)
Net engine power Gear 1 (ISO 9249)	149 kW (200 hp)
Net engine power Gear 2 (ISO 9249)	157 kW (210 hp)
Net engine power Gear 3 (ISO 9249)	168 kW (FT4) / 164 kW (T3 and T2) (225 hp (FT4) / 220 hp (T3 and T2))
Net engine power Gear 4 (ISO 9249)	172 kW (FT4) / 168 kW (T3 and T2) (230 hp (FT4) / 225 hp (T3 and T2))
Net engine power Gear 5 (ISO 9249)	179 kW (FT4) / 172 kW (T3 and T2) (240 hp (FT4) / 230 hp (T3 and T2))
Net engine power Gear 6 (ISO 9249)	187 kW (FT4) / 179 kW (T3 and T2) (250 hp (FT4) / 240 hp (T3 and T2))
Net engine power Gear 7 (ISO 9249)	190 kW (FT4) / 187 kW (T3 and T2) (255 hp (FT4) / 250 hp (T3 and T2))
Net engine power Gear 8 (ISO 9249); 6WD not available	190 kW (FT4)* / 179 kW (T3 and T2)* (255 hp (FT4)* / 240 hp (T3 and T2)*)
Net peak torque (FT4/Stage V)	1292 Nm (953 lb.-ft.)
6-wheel drive type	Automatic dual-path hydrostatic drive; separate left and right systems with variable-displacement pumps, axial-piston wheel motors; freewheel at transport speeds; 15-position rotary aggressiveness; inching to 0 mph; precision mode (front wheels only)
Transmission	same; 117 L/min gear pump (Direct-drive John Deere PowerShift Plus, modulated shift-on-the-go, Event-Based Shifting (EBS), inching pedal; independent reservoir with separate filtration and cooling, 31 gpm gear pump)
Gears forward / reverse	8F / 8R
Moldboard base (standard)	3.66 m x 610 mm x 22 mm (12 ft. 0 in. (144 in.) x 24 in. x 0.88 in.)
Cutting edge (Dura-Max through-hardened)	16 mm x 152 mm (0.62 in. thick x 6 in. wide)
Fuel tank	416.5 L (110 gal.)
Operating weight FT4 — front / rear / total (base spec condition)	4835 / 12 305 / 17 140 kg (10,660 / 27,128 / 37,788 lb.)
Maximum operating weight	24 948 kg (55,000 lb.)
A Height to top of cab	3.18 m (10 ft. 5 in.)
Travel speed Gear 8 (highest published)	45.5 km/h (28.3 mph)

F.A.Q.

2020 John Deere 672G — questions before you call.

(405) 873-7772 sales@trackandblade.com

Sales desk is 9 to 5 Central. Live Agent is on 24/7 — call, text, or chat.

What net horsepower does DKAGGDR672 publish for 672G/GP?

Variable by gear and emission column. FT4/Stage V PowerTech PSS 9.0L: Gear 1 149 kW (200 hp) through Gear 7-8 190 kW (255 hp), with Gear 8 asterisked 6WD not available. Tier 3/Tier 2 columns peak at 187 kW (250 hp) in Gear 7 and 179 kW (240 hp)* in Gear 8. Net power is ISO 9249. Dealer lot strings of 255 HP match the FT4 Gear 7/8 rating; dealer strings of 190 HP on two 2019 lot units are not a published FT4 672G gear row on this sheet (FT4 Gear 1 is 200 hp).

What is the published operating weight?

FT4/Stage V base condition (full fuel, 12-ft x 24-in x 0.88-in moldboard, 14R24 L2, 79 kg operator): 17 140 kg (37,788 lb.) total. Typical with front push block, rear ripper/scarifier, and other equipment: 20 000 kg (44,092 lb.). Maximum operating weight 24 948 kg (55,000 lb.). T3/T2 typical with the same attachments is 19 330 kg (42,615 lb.).

Fuel and DEF capacities?

Fuel tank 416.5 L (110 gal.) on both emission groups. DEF 22.5 L (6 gal.) on FT4/Stage V only (T3/T2 column blank). Do not substitute the live 672 G-Tier page figure 397 L (105 gal.).

Standard moldboard and cutting edge?

Base moldboard 3.66 m x 610 mm x 22 mm (12 ft. x 24 in. x 0.88 in. / 7/8 in. in additional equipment). Dura-Max cutting edge 16 mm x 152 mm (0.62 in. x 6 in.). Optional boards include 13-ft and 14-ft sizes on the option-weight table.
