2025 John Deere 35 P
2025 John Deere 35 P compact excavator. 259 hours. Listed from Lawton, OK. Stock 25096. Asking $59,330.
- Asking
- $59,330
- Hours
- 259
- Stock #
- 25096
- Location
- Lawton, OK
- Listed by
- CL Boyd
Sales desk 9 to 5 Central · Live Agent 24/7
Essentials
- Stock
- 25096
- Class
- Compact Excavators
- Engine
- Yanmar 1.64L 23.3 Net HP FT4 Diesel Engine
- Yard
- Lawton, OKSee what else is here.
- Sale
- No bidding · no premium
- Listed by
- CL Boyd
Specification
| Engine manufacturer | Yanmar |
|---|---|
| Engine model | 3TNV88F |
| Displacement | 1.642 L (100.2 cu. in.) |
| Engine cylinders | 3 |
| Net power (ISO 9249) at 2,400 rpm | 16.5 kW at 2,400 rpm (22 hp at 2,400 rpm) |
| Operating weight, cab, standard arm, standard counterweight | 3690 kg (8,135 lb.) |
| Maximum digging depth, standard arm | 3.06 m (10 ft. 0 in.) |
| Maximum digging reach, standard arm | 5.21 m (17 ft. 1 in.) |
| Tail swing radius, standard arm | 870 mm (34 in.) |
| Spec-basis bucket | 610 mm, 0.11 m³ (24 in., 4.0 cu. ft.) |
| Bucket digging force (ISO) | 27.1 kN (6,085 lb.) |
| Auxiliary hydraulic flow | 61.2 L/m (16.2 gpm) |
| Main pump flow (2 piston pumps) | 76.8 L/min (20.2 gpm) |
| Travel speed, high | 4.3 km/h (2.7 mph) |
| Fuel tank | 42 L (11.1 gal.) |
Sales desk is 9 to 5 Central. Live Agent is on 24/7 — call, text, or chat.
What engine does John Deere publish for the 35 P-Tier?
ME35PAU.pdf Manufacturer and Model: Yanmar 3TNV88F. Displacement 1.642 L (100.2 cu. in.). Three cylinders. EPA Final Tier 4/EU Stage IV. Rated speed 2,400 rpm.
What net power is on the spec sheet?
ME35PAU.pdf Net Power (ISO 9249): 16.5 kW (22 hp) at 2,400 rpm.
What operating weight is published?
ME35PAU.pdf with full fuel tank and 79-kg (175 lb.) operator, cab, 1315-mm (4 ft. 4 in.) standard arm and standard counterweight: 3690 kg (8,135 lb.). US and deere.ca heroes quote Operating Weight 8,135 lb. (3,690 kg) / 3690 kg (8,135 lb.). Canopy with standard arm: 3520 kg (7,760 lb.). Cab with long arm and extra counterweight: 3953 kg (8,715 lb.).
How deep does the 35 P-Tier dig?
ME35PAU.pdf Maximum Digging Depth with 1315-mm (4 ft. 4 in.) standard arm: 3.06 m (10 ft. 0 in.). With 1715-mm (5 ft. 8 in.) long arm: 3.46 m (11 ft. 4 in.). US and deere.ca heroes quote Max. Digging Depth / Digging Depth 10 ft. 0 in. (3.06 m). Maximum digging reach, standard arm: 5.21 m (17 ft. 1 in.).
What tail-swing figure is published?
ME35PAU.pdf Tail Swing Radius with standard arm 870 mm (34 in.); with long arm and extra counterweight 980 mm (39 in.). deere.ca Tailswing Radius 870 mm (2 ft 10 in). Additional equipment lists Zero-tail-swing configuration as standard.
What bucket is the spec sheet based on, and what bucket force is listed?
ME35PAU.pdf footnote: specifications based on a canopy unit with standard arm; 610-mm (24 in.), 0.11-m³ (4.0 cu. ft.) bucket; 300-mm (12 in.) rubber track; and 540-kg (1,190 lb.) counterweight. ISO bucket digging force 27.1 kN (6,085 lb.) on both arm lengths. Arm force 19.0 kN (4,277 lb.) standard arm; 16.9 kN (3,792 lb.) long arm.
What hydraulic flow is published?
ME35PAU.pdf open center with 2 variable-displacement pumps and 1 fixed-gear pump. Piston 2 x 38.4 L/m (2 x 10.1 gpm). Gear 22.8 L/m (6.0 gpm). Auxiliary flow 61.2 L/m (16.2 gpm). deere.ca Total Flow 76.8 L/min (20.2 gpm).
